The OS700X Triple Motor Surge Feeder is the world’s best system for the creation of extended content booklet labels. The OS700X easily integrates with any web press or can be integrated as part of an offline system and comes in a variety of widths. The OS700X easily integrates with OEM verification equipment such as bar code readers or vision systems.
| Specifications | ||
|---|---|---|
| Minimum Product Length | 7/8" | 22 mm |
| Maximum Product Length | 11" | 280 mm |
| Minimum Product Width | 2" | 51 mm |
| Maximum Product Width | 16½"" | 420 mm |
| Maximum Thickness | ¼" | 6 mm |
| Placement Tolerance | +/-0.020" | +/-.5 mm |
| Speed | Up to 35,000 pieces per hour | |
